FDM3DSPARS (<sparsity>);

Set spatial sparsity for FD-Monitor 3D.

DISPERSION2 (<mediumname>, <model_name>, <par_1>, <par_2>, <par_3>, <par_4>, <par_5>, <par_6>, <par_7>, <par_8>, <par_9>, <par_10>, <par_11>);

Sets multipole dispersive dielectric parameters.
The model_name options are: DRUDE2, DEBYE2, LORENTZ2, DEBYE_DRUDE, DEBYE_LORENTZ, DRUDE_LORENTZ, DRUDE3, DEBYE3, LORENTZ3, DEBYE2_DRUDE, DEBYE2_LORENTZ, DEBYE_DRUDE2, LORENTZ_DRUDE2, DEBYE_LORENTZ2, LORENTZ2_DRUDE, DEBYE_DRUDE_LORENTZ, DEBYE_ANIS.

DRUDE2: (<par_1>,…,<par_11>) - (eps_inf,v_c, f_p, Amp1,v_c2,f_p2,Amp2,0,0,0,0)
DEBYE2: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,tau2,Amp2,0,0,0,0,0)
LORENTZ2: (<par_1>,…,<par_11>) - (eps_inf,eps_s,v_c,f_p,Amp1,v_c2,f_p2,Amp2,0,0,0)
DEBYE_DRUDE: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,v_c2,f_p2,Amp2,0,0,0,0)
DEBYE_LORENTZ: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,v_c2,f_p2,Amp2,0,0,0,0)
DRUDE_LORENTZ: (<par_1>,…,<par_11>) - (eps_inf,eps_s,v_c,f_p,Amp1,v_c2,f_p2,Amp2,0,0,0)
DRUDE3: (<par_1>,…,<par_11>) - (eps_inf,v_c,f_p,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3,0)
DEBYE3: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,tau2,Amp2,tau3,Amp3,0,0,0)
LORENTZ3: (<par_1>,…,<par_11>) - (eps_inf,eps_s,v_c,f_p,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3)
DEBYE2_DRUDE: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,tau2,Amp2,v_c3,f_p3,Amp3,0,0)
DEBYE2_LORENTZ: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,tau2,Amp2,v_c3,f_p3,Amp3,0,0)
DEBYE_DRUDE2: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3,0)
DEBYE_DRUDE_LORENTZ: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3,0)
LORENTZ_DRUDE2: (<par_1>,…,<par_11>) - (eps_inf,eps_s,v_c,f_p,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3)
LORENTZ2_DRUDE: (<par_1>,…,<par_11>) - (eps_inf,eps_s,v_c,f_p,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3)
DEBYE_LORENTZ2: (<par_1>,…,<par_11>) - (eps_inf,eps_s,tau,Amp1,v_c2,f_p2,Amp2,v_c3,f_p3,Amp3,0)
DEBYE_ANIS: (<par_1>,…,<par_11>) - (eps_inf_x,eps_s_x,tau_x,eps_inf_y,eps_s_y,tau_y,eps_inf_z,eps_s_z,tau_z,0)

DISPERSIONH2 (<mediumname>, <model_name>, <par_1>, <par_2>, <par_3>, <par_4>, <par_5>, <par_6>, <par_7>, <par_8>, <par_9>, <par_10>, <par_11>);

Sets multipole dispersive dielectric parameters.
The model_name options are: DRUDEH2, DEBYEH2, LORENTZH2, DEBYEH_DRUDEH, DEBYEH_LORENTZH, DRUDEH_LORENTZH, DRUDEH3, DEBYEH3, LORENTZH3, DEBYEH2_DRUDEH, DEBYEH2_LORENTZH, DEBYEH_DRUDEH2, LORENTZH_DRUDEH2, DEBYEH_LORENTZH2, LORENTZH2_DRUDEH, DEBYEH_DRUDEH_LORENTZH.

DRUDEH2: (<par_1>,…,<par_11>) - (mu_inf,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,0,0,0,0)
DEBYEH2: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,tau2H,Amp2H,0,0,0,0,0)
LORENTZH2: (<par_1>,…,<par_11>) - (mu_inf,mu_s,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,0,0,0)
DEBYEH_DRUDEH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,v_c2H,f_p2H,Amp2H,0,0,0,0)
DEBYEH_LORENTZH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,v_c2H,f_p2H,Amp2H,0,0,0,0)
DRUDEH_LORENTZH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,0,0,0)
DRUDEH3: (<par_1>,…,<par_11>) - (mu_inf,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H,0)
DEBYEH3: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,tau2H,Amp2H,tau3H,Amp3H,0,0,0)
LORENTZH3: (<par_1>,…,<par_11>) - (mu_inf,mu_s,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H)
DEBYEH2_DRUDEH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,tau2H,Amp2H,v_c3H,f_p3H,Amp3H,0,0)
DEBYEH2_LORENTZH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,tau2H,Amp2H,v_c3H,f_p3H,Amp3H,0,0)
DEBYEH_DRUDEH2: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H,0)
DEBYEH_DRUDEH_LORENTZH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H,0)
LORENTZH_DRUDEH2: (<par_1>,…,<par_11>) - (mu_inf,mu_s,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H)
LORENTZH2_DRUDEH: (<par_1>,…,<par_11>) - (mu_inf,mu_s,v_cH,f_pH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H)
DEBYEH_LORENTZH2: (<par_1>,…,<par_11>) - (mu_inf,mu_s,tauH,Amp1H,v_c2H,f_p2H,Amp2H,v_c3H,f_p3H,Amp3H,0)
