QW-Modeller

QW-Modeller

version 2017

Welcome to the QW-Modeller 2017 documentation containing complete help for QW-Modeller for QuickWave software for electromagnetic design and simulations based on the conformal FDTD method.

QW-Modeller is a free CAD modeller for QuickWave and can be downloaded from QWED’s website.

The QW-Modeller 2017 help documentation contains the following chapters:

QW-Modeller 2017 overview: an overview of installation of QW-Modeller, QW-Modeller Updates and QuickWave architecture.
QW-Modeller 2017 Users’ Manual: an overview of QW-Modeller 2017
QW-Modeller 2017 Getting Started: the basis of QW-Modeller user interface and brief description about geometry creation and geometrical operations
QW-Modeller 2017 Examples Guide: a brief description of all QW-Examples included in the QW-Modeller installation

To facilitate using QuickWave in microwave courses, the examples investigating basic electromagnetic scenarios are included, as well as a short background description. These examples, together with microwave background description, become complementary introductory to fundamental microwave phenomena:

Microwave Course: examples investigating basic electromagnetic scenarios as well as a short background description.

See also the QuickWave 2017 documentation containing complete help for QuickWave software for electromagnetic design and simulations based on the conformal FDTD method and for QuickWave optional modules:

· QuickWave 2017 documentation
