QuickWave

Help for

QuickWave^TM

version 2024

Welcome to the QuickWave 2024 documentation containing complete help for QuickWave software for electromagnetic design and simulations based on the conformal FDTD method and for QuickWave optional modules.

The QuickWave 2024 help documentation contains the following chapters:

QuickWave 2024 overview: an overview of installation of QuickWave, QuickWave License Manager, QuickWave Updates and QuickWave architecture.
General information about QuickWave: description of functionalities, method, processings and post-processings available in the QuickWave software.
QW-Editor: description of the QuickWave Editor, graphical user interface, media, excitation, ABC, project preparation and FDTD meshing.
QW-Simulator: description of the QuickWave Simulator, graphical user interface, FDTD simulation, watching simulation results and fields distribution.
User Guide for 3D projects: examples guide of the 3D projects included in the QuickWave installation.
User Guide for V2D projects: examples guide of the V2D projects included in the QuickWave installation.
Basic Heating Module: description of the Basic Heating Module.
QW-OptimiserPlus: description of the multiobjective optimiser integrated with QW-Simulator.
QProny: description of the QProny module for fast analysis of a high Q structures and loaded Q calculations.
QW-AddIn for Autodesk® Inventor® Software: description of the QuickWave plugin for Autodesk® Inventor® Software CAD tool.
QW-Modeller: description of the free CAD modeller for QuickWave.
