Plano-Concave Fabry-Perot Open Resonator
Bulk Metal
rigid sheets or plates of highly-conductive metals (e.g., copper, silver, aluminium).
Conductive foils
thin, flexible metal foils such as rolled copper; the resonator probes their surface conductivity even at micrometre-level thicknesses.
Copper-Clad laminates
PCB-grade dielectric panels coated with copper; the instrument measures the electrical conductivity of the copper cladding.
|
20 – 50 GHz |
|
5 × 104 – 6 × 107 S/m (achievable accuracy < 5%) |
|
≥ 5 skin depths (e.g., a few µm for Cu) |
|
150 – 195 mm |
|
a few minutes |
|
|
Overview
